450plus – 12V/24V Wind Turbine 500W Generator

Out of stock
Regular price £315.00 inc. VAT
System Voltage

450Plus Wind Generator | 12V / 24V


Compact Wind Power with Refined Engineering

The 450Plus is a compact and efficient wind generator designed for reliable energy production in 12V or 24V systems. With its modern rotor blade design, durable construction and low-maintenance engineering, the 450Plus offers a strong balance of performance, stability and long service life.

Developed with a focus on practical wind energy generation, this wind generator combines aerodynamic efficiency with robust materials to deliver dependable operation in changing wind conditions.


Designed for Efficient Energy Generation

The 450Plus has been engineered to convert wind into usable electrical energy with smooth and stable performance. Its newly developed rotor blades are shaped for improved aerodynamic behaviour, helping support efficient rotation and consistent power generation.

The system is available in 12V or 24V configuration, allowing the turbine to be matched with the correct battery system and compatible wind charge controller.

Technical Datasheet

IstaBreeze 450Plus 12V/24V Wind Turbine

High-performance wind turbine designed for 12V and 24V battery-based wind energy systems.

Maximum Power 500 W
Rated Power 420 W
Rotor Diameter 103 cm
Start Wind Speed 3 m/s

Wind Turbine Specifications

Current
40 A at 12 V / 20 A at 24 V
Alternator Body
Aluminium
Body Material
Aluminium casting
Maximum Power
500 W
Rated Power
420 W
Voltage
12 V AC / 24 V AC
Package Dimensions
Package 1: 70 × 30 × 20 cm
Total weight: 6 kg

Wind Speed Data

Initial Wind Speed
3 m/s
Maximum Wind Speed
14–15 m/s

Blade Specifications

Blade Material
Composite or Carbon
Blade Length
50 cm
Rotor Diameter
103 cm
Noise Level
40 dB (Composite)
Blade Weight
190 g (Composite)
Blade Width
10 cm

Required Equipment

Battery Group
Suitable battery group: min. 1800 W – max. 2400 W
For safe and efficient operation, this wind turbine should be used with a compatible charge controller and a suitable battery system.
